Full Automatic Medium Speed Paper Dish Forming Machine
Pneumatic paper dish forming at 50–70 pieces per minute with 5-ton pressing force.
Industrial paper dish forming machine designed for small to medium factories requiring fast changeover between dish sizes and paper weights. Pneumatic-mechanical design eliminates hydraulic oil contamination while delivering consistent 5-ton pressing force for food-grade packaging production.
Key Specs
Key Specs
Power
Weight
Dimension
Overview Points
Pneumatic Forming Speed
Multi-Weight Capability
Versatile Dish Sizes
Full Automation
Standard Power Input
Compact Installation
Standard Air Supply
Custom Tooling Support
Key Features
The MPT-80-150-5T-10 booster cylinder delivers up to 5 tons of pressing force through compressed air alone, achieving consistent dish formation across paper weights from 140 to 800 g/m². This pneumatic approach eliminates hydraulic oil leaks, reduces maintenance intervals, and meets cleaner production standards required for food-contact packaging lines.
Integrated heating elements with constant temperature regulation ensure uniform heat distribution across the forming die surface. Consistent die temperature prevents under-formed edges on heavy cardboard and scorching on lighter paper stock, resulting in reliable dish geometry and surface finish across extended production runs.
The machine handles the complete cycle — pneumatic paper suction, sheet feeding, heated pressing, dish ejection, and piece counting — without operator intervention during production. This reduces labor to one person managing material input and output stacking, cutting direct labor costs compared to semi-automatic alternatives.
Interchangeable molds accommodate round dishes from 4 to 11 inches, square dishes, and custom shapes. Mold changeover enables a single machine to serve multiple product SKUs, which is particularly valuable for contract manufacturers producing varied dish specifications for different end customers.
At 3 kW on standard 220V single-phase supply, the machine operates without dedicated transformers or heavy electrical infrastructure. The 1400 × 1480 mm floor footprint allows installation in compact workshops, and the 600 kg weight requires no special foundation preparation.
Technical Specifications
This machine is a medium speed automatic paper dish machine which is developed and designed according to the market demand. It has the functions of self-pneumatic paper sucking and feeding, heating forming, automatic dish releasing, constant temperature control, automatic counting, etc. It is an ideal equipment for producing circular paper dish, square paper dish and special-shaped paper dish of various specifications.
Compared with the traditional automatic paper disc machine, it recombines the principle of pneumatic and mechanical combination, and has the advantages of higher production speed, more stable performance, safer operation, more convenient dimension and more humanized structure design.
Fully automatic medium speed paper disc machine with high efficiency of the pressurized cylinder, the maximum pressure up to 5T, it has the advantages of faster and more environmental protection than the oil cylinder.
This medium speed automatic paper dish machine is widely used in the production of paper or aluminum foil based dishes. Round or square plates and plates of different sizes and shapes can be produced by changing molds.
| Size of paper dish: | 4–11 inches (diameter, round paper dish) (mould is interchangeable) |
| Paper materials: | 140– 800 g/m2 (base paper, white board paper, white cardboard paper, aluminum foil or other); Production speed: 50-70 / min |
| Power requirement: | 220V 50Hz; Total power rate: 3 KW; |
| Machine weight: | 600kg; |
| External dimension: | (length x width x height)1400x 1480 x 1700mm; |
| Supporting air source requirements: | working pressure 0.8mpa, working air capacity 1.5m3 / min; Other remarks: We can customize the production of various specifications of paper disc machinery according to customer’s requirements. |
| Main technical parameters of booster cylinder: | MPT – 80-150-5 t – 10 |
| Air flow: | 1.5 m3 / min |
| Air pressure: | 0.5-0.8mpa |
| Cylinder stroke: | 150mm |
Applications
Disposable paper plate and dish manufacturing for food service and catering supply
Aluminum foil dish production for takeaway food packaging
Event and party supply manufacturing — round and shaped paper plates
Contract packaging factories producing multi-SKU disposable tableware
Small and medium enterprises entering the paper dish market with limited floor space
Export-oriented paper product factories requiring versatile, mold-changeable forming equipment
Video
FAQ
The key specifications of Full Automatic Medium Speed Paper Dish Forming Machine include: Power: 220V 50Hz; Total power rate: 3 KW;, Weight: 600kg;, Dimension: (length x width x height)1400x 1480 x 1700mm;. Contact us for the full specification sheet.
Full Automatic Medium Speed Paper Dish Forming Machine is widely used in: Disposable paper plate and dish manufacturing for food service and catering supply; Aluminum foil dish production for takeaway food packaging; Event and party supply manufacturing — round and shaped paper plates; Contract packaging factories producing multi-SKU disposable tableware.
All NTBOBO machines come with a 1-year warranty from the date of Bill of Lading. Our engineering team provides 24-hour technical support throughout the warranty period.
We accept 30% down payment by T/T (Telegraphic Transfer), with the balance due before shipment. Other payment arrangements can be discussed for long-term partners.
Standard delivery is within 10-35 working days after receiving the down payment, depending on the machine model and customization requirements.
